Anyang Gaokang Medical Co., Ltd. is one of the most reliable manufacturers and suppliers of fluidized spray dryer in China. With a professional production team, we are able to meet the needs of the majority of our customers. Please rest assured to buy premium fluidized spray dryer at competitive price from our factory.
Product Introduction
The working principle of fluidized spray dryer is mainly based on spray drying technology. The specific process is as follows:
- After air is filtered and heated, it enters the air distributor at the top of the dryer, and the hot air enters the drying chamber uniformly in a spiral shape.
- The material liquid (such as vulcanised colloid, etc.) is sprayed into very fine mist beads by the high-speed centrifugal atomiser at the top of the tower.
- The mist beads and the hot air in parallel contact, in a very short period of time to evaporate water and dry for the finished product.
- The finished products are continuously output from the bottom of the drying tower and the cyclone separator, and the exhaust gas is exhausted by the fan.
parameters
Please refer to the following fluidized spray dryer parameters. Customization is supported.
|
Item Model |
LPG-5 |
LPG-50 |
LPG-150 |
LPG-200~2000 |
|
Inlet temp. ºC |
140~350 |
140~350 |
140~350 |
140~350 |
|
Outlet temp. ºC |
80~90 |
80~90 |
80~90 |
80~90 |
|
Max. water evaporation kg/h |
5 |
50 |
150 |
200~2000 |
|
Transmission form of centrifugal atomizer |
Compressed air transmission |
Mechanical transmission |
Mechanical transmission |
Mechanical transmission |
|
Maximum speed (r.p.m) |
25000 |
18000 |
15000 |
8000-15000 |
|
Diameter of atomizer (mm) |
50 |
120 |
150 |
180-240 |
|
Heat source |
Electricity |
Electricity, steam, natural gas, LPG |
||
|
Max. power of electric heater (kw) |
9 |
72 |
99 |
|
|
Overall dimensions (LWH) (m) |
1.8*0.93*2.2 |
3.5*3.5*4.8 |
5.5*4*7 |
|
|
Dry powder recovery rate (%) |
≥95% |
|||
|
Note: The amount of water evaporation is related to the characteristics of the material and the temperature of the hot inlet and outlet. |
||||
Product Advantage
Advantages of Fluidized Spray Dryer：
1. Special for lab research, Min 20-30ml liquid to finish one test.
2. All borosilicate glass for easy visual monitoring of process status.
3. Spray chamber, cyclone separator, receiving tank are all made of Borosilicate glass which can resist strong acid/alkali, high temperature. It can work in a no-pollution and stable environment.
