Products Description
FD-10 Model Vacuum freeze dryer machine is widely used in medicine, pharmacy, biology research, chemical industry and food production ,etc. After the freeze drying process, a long term preservation for products is much easier. They can be restored to the original state and maintain their chemical and biological characteristics after being watered.
Parameters
| Model | FD-10A |
| Freeze drying area | 0.12 |
| Condenser capacity | 3-4 L /24h |
| Condenser temperature | -55ºC (-80 ºC optional) |
| Vacuum degree | < 10 Pa |
| Material tray | Ф200mm , 4 layers |
| Bulk capacity | 1.2L, 10mm thickness |
| Vial capacity Φ12mm | 920 pcs |
| Vial capacity Φ16mm | 480 pcs |
| Vial capacity Φ22mm | 260 pcs |
| Manifold | with 8 ports |
| Flask | 1000ml,500ml ,250ml ,100ml |
| Cooling | Air,draughty , ambient temperature≤25ºC |
| Voltage | 220V ,50 Hz; 110V, 50Hz; 110V, 60Hz |
| Power | 700W |
| Dimension | 460×625×(370+465) mm |
| Host weight | 41 kg |
Features
Vacuum freeze dryer machine structure:
- Color LCD touch screen ,English control panel,display freeze drying curve, save data;
- Big opening condenser has pre-freezing function;
- CFC-free refrigerant, low noise compressor, good efficiency,long service life;
- Condenser ,trays, drying shelf are all stainless steel 304;
- Acrylic drying Chamber safe and visible.
Details photos
How to choose the right experimental freeze-drying equipment?
This paper describes TP(Top press) Vacuum freeze dryer machine:
1. Suitable for lab vials and bottled materials, can be used in various freeze-drying experiments in the laboratory.
2. Great cold trap temperature -60℃.
3. Excellent cooling ability. Under no-load condition, the cold trap temperature reaches the minimum temperature specified by the index within 1 hour.
4. Vacuum within a reasonable range.
5. The temperature of the board is uniform.
6. The control system should be able to display the freeze-drying process parameters in real time and record them automatically. With communication interface, easy to collect and save data.
Welcome to inquiry~I will match suitable Vacuum freeze dryer machine model accoring to your needs.
