Description
The cream separator for goat milk is primarily used for skimming milk, whey protein isolation, butter production, wheat shock shower, casein production, cheese production, anhydrous butter centrifuge enrichment, and other processes in medium to large dairy industry enterprises. The equipment features a closed structure, with all milk-contact parts made of stainless steel, in line with national food hygiene standards. According to user requirements, it can also be used for milk, milk residue, condensed casein, protein, and whey protein isolation, as well as whey clarification and purification.
Main Features
- The machine starts using friction, taking about six to ten minutes. It runs smoothly with low noise and vibration, making the installation path very easy to operate.
- The bearings use imported FAG, the transducer is from the Japanese brand "Fuji," and the main strengthened parts of the roller body and roller cover use 2Cr13. Other parts that contact materials, such as the disc, are made of 304L.
- The stainless steel cover uses SUS304.
- The base is made of cast steel, with coating applied in the same way as a ship's bottom.
Specifications of cream separator for goat milk
|
Rated capacity L/H |
1500(when tested by water) |
2000 |
|
Drum agitating speed r/min |
8300 |
7350 |
|
Drum diameter mm |
¢230 |
¢265 |
|
Separation factor |
9630 |
8300 |
|
The way of cleaning |
Clean by hand |
Clean automatically |
|
Centripetal pump output pressure Mpa |
≤0.2 |
≤0.2 |
|
Power |
3KW |
4KW |
|
Weight |
240kg |
360kg |
|
Dimension |
850*720*1000mm |
830*800*1150mm |
Main parts of cream separator for goat milk
- Access Device: Facilitates the entry and exit of milk.
- Drum: The central component where the separation process occurs, designed to handle high-speed rotation.
- Paring Disc Device: Ensures the efficient separation of cream from milk.
- Drive System: Provides the necessary power to the drum for rotation, ensuring smooth and efficient operation.
- Stainless Steel Cover: Protects internal components and maintains hygiene by preventing contamination.
- Engine Base: The robust foundation that supports the entire machine, ensuring stability during operation.
- Motor: Powers the drive system, ensuring efficient and consistent machine operation.
