Anyang Gaokang Medical Co., Ltd. is one of the most reliable manufacturers and suppliers of yeast bioreactor in China. With a professional production team, we are able to meet the needs of the majority of our customers. Please rest assured to buy premium yeast bioreactor at competitive price from our factory.
Products Description
Yeast Bioreactor enables yeast to efficiently utilize sugar for fermentation by providing a suitable environment, including temperature, pressure and oxygen supply, so that the sugar can be converted into alcohol and carbon dioxide.
Yeast Bioreactor are used not only for the production of conventional bread, but also for the production of organic products and allow for individualized settings for production.It promotes effective yeast fermentation by providing a suitable fermentation environment, which in turn affects the quality and productivity of the bread.
Product structure
Work Principle
The Yeast Fermenter Bioreactor achieves effective yeast fermentation through the provision of suitable environmental conditions, effective mixing of materials and nutrient contact, precise control of the mass transfer process, effective management of heat, the application of the principle of aeration, as well as the application of optimization and amplification technology, thus producing high-quality bread products.
Product Specification
|
Part Name |
Parameter&Description |
||
|
Model |
GK-BIO-5 / GK-BIO-7 / GK-BIO-10 |
RY-BIO-7 |
GK-BIO-10 |
|
Full Volume(L) |
5L / 10L / 10L |
7L |
10L |
|
Working volume |
1.0~3.5 / 2.0~5 / 3.0~7.0 |
2.0~5 |
3.0~7.0 |
|
Diameter: height |
1 : 2-2.5 |
||
|
Product Standard |
Standard GMP |
||
|
Material |
Borosilicate glass + 316L stainless steel |
||
|
Sterilization method |
Sterilization in place |
||
|
Air intake filter |
Germany Sartorius |
||
|
Control System |
GK Siemens PLC control system |
||
|
Display |
10.4〞Touch Screen |
||
|
Temperature Control System |
Temperature Sensor: Pt100 platinum electrode (quick disassembling under high temperature resistant); Sterilization temperature: up to 130°C |
||
|
Foam System |
Sensitivity between 100~100000Ω; Foam can be automatically detected by the defoaming electrode, and the controller controls the peristaltic pump to automatically add defoaming agent |
||
|
PH Control |
PH range: 2-12pH; Resolution: 0.01 pH; |
||
|
DO Control |
Testing Range: 0-300%; Resolution: 0.1%. |
||
|
Pressure |
Control by man-hand; Range: 0-0.05MPa. |
||
|
Air Intake |
Control by man-hand; Displayed by flowmeter; Range: 0-10L/min. |
||
|
Optional Control |
Liquid level control, feeding weighing system, two-way feeding, online detection of methanol and ethanol content, exhaust oxygen and carbon dioxide detection, etc. |
||
Features
- Degree of automation to improve production efficiency
- Study of the multilevel problem and its bioreactor plant technology
- Characteristics of fermenter insulation systems
Our Advantages
1. Factory sales equipment.
2. Professional technology, complete specification and reasonable price.
3. MOQ 1unit.
4. ISO CE certification.
5. The strong support of advanced tachnology and detection capability.
6. Professional service including installation guide.
7. Quickly delivery about 1-3months.
Application
Food, beverage, brewing and other industries
Biochemical fermentation production: monosodium glutamate, citric acid, etc
Cultivation of microorganisms and cell cultures
