Large Scale Fermentor Description

Large Scale Fermentor, high-efficiency fermentation equipment, with advanced control system to ensure stable production environment, suitable for food, pharmaceutical, chemical and other fields, to enhance the fermentation efficiency and product quality.

Large Scale Fermentor structure

The following equipment structure is for reference.

Industrial Fermentation Tank

parameters

The following Large Scale Fermentor parameters are for reference.

Parameter	Description
Total volume	5L,10L,15L,20L,30L,50L,100L,200L,500L etc.
Working volume	30%~70%
Tank	Jacket tank, made by SS316 and SS304, tank design pressure 0.3Mpa, jacket design pressure 0.35Mpa, polishing 0.4-0.6um, ratio of diameter and height is 1:2.2-2.5
Anti-foam control	Automatically add antifoam by peristaltic pump
Temperature control	Auto-control, electric heating range: water source add 5ºC to 70ºC
PH control	PH 2.00-12.00±0.1, auto-control adding acid/base by peristaltic pump, pH sensor from Hamilton/Mettler, Switzerland.
Do control	0-150±3% displaying precision 0.1%, DO sensor from Hamilton/Mettler, Switzerland. DO coupling with agitation, oxygen.
Sampling	Sampling valve, can sterilization separately, manual
Harvest	Zero dead zone bottom valve(Burket,Germany), can sterilization separately, manual/auto
Lid lift system	30L-500L have lid lift system, 700-1000L have human hole.

Large Scale Fermentor Features

Zero-Dead-Zone Harvest: A bottom harvest valve (from Burket, Germany) ensures complete product recovery, maximizing yield. The valve and the separate sampling port can be sterilized in-place, maintaining aseptic integrity.

Ergonomic Access: For operator safety and convenience, models from 30L to 500L are equipped with a lid lift system. Larger vessels feature a standard manhole for direct internal access.

Design: The tank and jacket are built to withstand process demands with design pressures of 0.3Mpa and 0.35Mpa, respectively.
