Product Description
Laboratory mixing equipment consists of double cone, mechanical seal, frame, deceleration drive and so on. The mixing barrel can be tilted at any angle, which is convenient for discharging and cleaning.
parameters
The following laboratory mixing equipment parameters are for reference and support customization.
| Model | Power (KW) | Capacity (L/Volume) |
Max Mixing Powder Weight(kg/batch ) |
Mixing time (mins/batch) | Size: L*W*H (cm) |
| GK100 | 3 | 280 | 100 | 6--8 | 180*70*150 |
| GK300 | 4 | 480 | 300 | 6--8 | 240*80*190 |
| GK500 | 5.5 | 700 | 500 | 8--10 | 270*90*200 |
| GK1000 | 7.5 | 1500 | 1000 | 8--10 | 310*110*200 |
| GK1500 | 11 | 2100 | 1500 | 8--12 | 310*110*200 |
advantages
1.Efficient Mixing:
- Laboratory mixing equipment mixes all kinds of powders evenly by rotating tank. When working, the motor and reducer drive the mixing tank through gear transmission, so that the materials are repeatedly polymerised and separated by gravity and centrifugal force, thus achieving the effect of homogeneous mixing.
2. Reasonable design:
-The tank is made of steel plate, the shape is a short cylinder set between two cones, the top angle of the cone is decided according to the resting angle of the mixed powder, which is convenient for discharging.
3. Easy to operate:
-Laboratory mixing equipment is very convenient to load and unload, add raw materials and several different auxiliary materials at one time when feeding, then close the lid and start the machine to mix according to the set time.
application
Laboratory mixing equipment is widely used in pharmaceutical, chemical, food, feed, fuel, electronics and other industries. It is suitable for all kinds of powdery, granular material uniform mixing, has a high degree of mixing, for adding a small amount of ingredients can also achieve a good degree of mixing.
