Dry Leaves Grinding Machine Introduction

Spindle drive motor and high-speed rotating turbines, tubo-screen with circle on the composition of the broken pieces of grinding, plus mateials from the hopper into the machine in the cavity, the materials in the turbine rotating in the air close to friction and strong. The impact of the turbine blades on the inside, and grinding the leaves and pieces of gap between the ground again.

Product Parameters

Model	GK-200	GK-300	GK-400	GK-500
Production capacity (kg/h)	60-100	80-300	100-400	120~500
Spindle speed(r/min)	4500	3500	3400	2900
Feed size (mm)	<6	<10	<12	<12
Crushing size(mesh)	20-400	20-400	20-400	20-400
Crushing motor (Kw)	4	7.5	11	22
Draught fan (Kw)	2.2	2.2	2.2	2.2
discharging motor (Kw)	0.75	0.75	0.75	0.75

advantages

Dry Leaves Grinding Machine has following benefits：

High quality

Especially suitable for the crushing of hard materials containing less fiber.

Advanced equipment

The air volume in the machine cavity is large, and the machine cavity is not easy to heat.

Professional team

Dry Leaves Grinding Machine has the advantages of smooth operation, convenient disassembly and cleaning, low noise and good crushing effect.

Global shipping

It has special effect on material with fiber, like herb.

about us

Why choose Us

1.Dry Leaves Grinding Machine is made up of stainless steel( we also can do as consumer requirement)

2.This machine meeting iso 9001 and SGS certificate

3.This machine match the turbine blade, it is also can match other different blade( if consumer need, we can design. so the consumer can change different blade to use)

4.This machine can add the water cooling system( as consumer requirement)

5.This machine can add the magnetic, to remove the Metal impurity( as consumer requirement)

6.This machine is automatic discharging, no need hand to control

7.This machine match the general dust absorption system, it also can match the pulse dust absorption system
