ZP Series (Rotary) – High-Volume & GMP Compliance
High-speed continuous production
Tablet Press Machine Equipped with 5-33 stamping station, the sturdy rotating structure achieves an efficient output of 9,000–40,000 tablets per hour, suitable for pilot production and small-scale to medium-scale mass production, meeting the requirements of continuous production.
Precise control and uniformity
It has a dual-level pressing system of pre-pressing and main pressing, with a pressure range of 40–80 kN. It adopts a PLC touch screen control system, which can adjust the rotational speed, filling depth and pressure in real time, ensuring small weight differences, consistent hardness and stable quality of tablets.
GMP-compliant design
The fully enclosed stainless steel contact surfaces are equipped with transparent observation windows and isolated transmission systems, effectively preventing cross-contamination and meeting the strict hygiene and cleanliness standards of the pharmaceutical and nutritional products industry.
Technical Versatility Across Models
| Model | Dies 16 | Dies 23 | Dies 26 | Dies 28 | Dies 32 | Dies 40 |
|---|---|---|---|---|---|---|
| Max. Main Force (kN) | 100 | 80 | 100 | 80 | 80 | 80 |
| Max. Tablet Ø (mm) | 25 | 16 | 25 | 13 | 16 | 13 |
| Max. Fill Depth (mm) | 20 | 16 | 20 | 16 | 16 | 16 |
| Turret Speed (rpm) | 11-87 | 11-105 | 11-87 | 11-105 | 11-105 | 11-105 |
| Capacity (tablets/h) | 30k-91k | 30k-144k | 30k-160k | 30k-185k | 30k-210k | 30k-260k |
| Power (3Ph, 380V) | 7.5 kW | 5.5 kW | 11 kW | 4 kW | 7.5 kW | 7.5 kW |
Core Features Ensuring Quality & Compliance
GMP-Certified Construction: A fully enclosed outer shell and internal contact surfaces crafted from high-grade stainless steel guarantee product integrity, surface finish, and compliance with hygiene regulations. Cross-contamination is effectively prevented.
Transparent Operation & Easy Maintenance: Integrated plexiglass viewing windows provide clear visibility of the compression process. Full-opening side panels offer exceptional access for rapid cleaning, tooling changes, and routine maintenance.
Intelligent Control & Stability: User-friendly mechatronic integration features touchscreen controls and digital displays. Smooth, variable-frequency drive (VFD) electrical speed regulation ensures precise turret control and operational stability.
Built-in Protection & Safety: Automatic overload protection instantly halts the machine during pressure excursions, safeguarding both personnel and tooling.
Enhanced Durability & Cleanliness:
- Our exclusive semi-automatic lubrication system extends critical component life.
- The plexiglass dust cover minimizes particulate escape at the turret.
- A dedicated powder suction system actively removes dust from the compression zone.
- The entire transmission operates sealed within an oil bath reservoir – ensuring cooling, reducing wear, eliminating contamination risk, and simplifying maintenance.
Efficient Standardization: Key wear components (upper punch rails, feeders, hoppers, worm drives, powder measures) share commonality with the established ZP33 series, streamlining spare parts inventory and reducing downtime.
Application
Designed for Your Productivity
Whether producing standard round tablets, complex geometric shapes, sophisticated double-layer formulations, or printed annular tablets, our press delivers consistent results. The optimized layout of all controls ensures intuitive operation. With dimensions of 1200 x 950 x 1850 mm and a robust weight (1200-1400 kg), our machines offer a powerful footprint designed for reliability.
Commitment to Excellence
We engineer our Tablet Press Machine to be more than just equipment; they are a reliable partner in your quest for efficient, compliant, and high-quality tablet manufacturing. Experience the difference precision engineering and thoughtful design make. Contact us to find the optimal Tablet Press Machine for your production requirements.
