Products Description
Tissue culture incubator is designed to meet the needs of modern industrial and academic cell culture laboratories.
Tissue culture incubator are designed to maintain a constant temperature and high humidity to support the growth of tissue culture cells in a CO2 atmosphere. Typical temperature settings range from 4°C to 50°C and CO2 concentrations from 0.3% to 19.9%.
The interior is typically made of non-corrosive stainless steel, with some newer models featuring antimicrobial copper surfaces to prevent contamination. Some models also feature automatic sterilization using heat or UV light.
Temperature control can be achieved through water bath circulation or radiant heating with electric filaments, and some units also include refrigeration. Relative humidity is maintained at 95 to 98 percent by a misting system or water bath.
Product Structure
Product Parameters
| Model | JX 2023R (273L) |
| Timing Range | 0 – 999h59mins / continuous |
| Temperature Range | 4°C-60°C (ambient temperature -15°C, minimum 4°C) |
| Temperature Accuracy | ±0.1°C (Constant temperature) |
| Temperature Uniformity | ±0.5°C at 37°C |
| Temperature Recovery Time | ≤±10mins |
| Ambient Temperature Range | 18-34°C |
| Humidity Control | Ambient ~ 95%RH |
| CO2 Control Range | 0.1-20% |
| CO2 Control Accuracy | 0.001 |
| CO2 Stability | ±0.1% |
| CO2 Accuracy | ±0.3% |
| CO2 Sensor | Infrared (IR) sensor high temperature resistance |
| HEPA Filter | The incoming gas is sterilized by the 0.2um online filter |
| Sterilization Method | UV sterilization |
| Concentration Recovery Time | ≤5mins to open the door for 30S |
| Heating Power | 800W |
| Cooling Power | 200W |
| Power Supply | AC 220V±10%, 50/60 Hz; 110V±10%, 60Hz(External transformer for 2022R) |
| Maximum Capacity | 250ml×60 or 500ml×40 or 1000ml×28 or 2000ml×15 or 5000ml×7 |
Tissue culture incubator is widely used in neuroscience, cancer research, embryonic cell research, stem cell research, tissue engineering, etc.
FAQ
FAQ
Q:1.what is Optional Accessories for Tissue culture incubator ?
A:- Optional built-in blackout curtain, free retractable to realize complete blackout.
- Optional oscillator for microplate and deep-well plate with 3mm amplitude and 800-1000rpm for maximum oxygen transfer efficiency.
- Optional expandable lighting, humidity control, remote communication monitoring and mobile APP function.
Q:2.what is material of Working chamber material for Tissue culture incubator ??
A:The working chamber is made of 304 stainless steel plating material with curved corner design for easy cleaning.
Q:3.Does it have Data storage and export?
A:With real-time curve view and historical data storage and export function, it can store more than 15 million data and record more than 5 years.
Q:4.what is Humidity Control range of tissue culture incubator?
A:Humidity control ranges from ambient humidity to 95% RH, ensuring precise humidity conditions in the culture environment.
Q:5.What are the typical maintenance intervals for this type of incubator?
A:Cleaning at least once every three months, including removal of all materials and components (shelves, water dishes and shields), cleaned, put back and filled with water.
Q:6.Does this issue culture incubator can print data ?
A:Built-in printer and USB interface, convenient for data output and transmission.
