Products Description
Ultra fine powder grinding machine comprised of main frame, auxiliary machine and electrical control cabinet, this machine has such performances as winnowing, screen or mesh free, uniform size and continuous operation, and has reached the international advanced level, thus being widely used for material crushing in chemical and foodstuff trades etc.
Products parameter
| Model | Capacity (kg/h) | Feed Size (mm) | Fineness (mesh) | Power (KW) | Dimension (mm) |
| GK-20 | 60-150 | ≤6 | 20~150 | 4 | 550×600×1250 |
| GK-30 | 100-300 | ≤10 | 20~150 | 7.5 | 600×700×1450 |
| GK-40 | 160-500 | ≤12 | 20~150 | 11 | 800×900×1600 |
| GK-60 | 300-1500 | ≤12 | 20~150 | 22 | 1600×1000×1470 |
| GK-80 | 500-2000 | ≤15 | 20~150 | 30 | 1750×1100×1610 |
Working principle
Ultra fine powder grinding machine:
The material is crushed by impact and friction of the teeth or pin between movable and fixed disks under the relative motion. Use a cloth bag to collect the final product at the discharging port.
Application case
What we use in production
Soybean
Coffee bean
Ginger
Pepper
- Food: Biscuit, Cocoa press cake, Dried peas, Potato starch, rice, Soy Protein, Sugar, Cocoa, Wheat gluten, Fennel, Cumin, Corn,
- Pepper, Soybean meal, Garlic, Pumpkin, Spices, sesame seeds, chili, onion, Ginger, Tea Powder
- Pharmaceuticals: Herbal medicine, Analgesics, Laxatives, Anti-convulsant, Gastric reflux, suppressants, Vitamins, Cultures, Aspirin,
Paracetamol
- Chemical: Carbonates, Chlorates, Chlorides, Citric Acid, Fertilizers, Fungicides, Gum Arabic, Gypsum, Hexamine, Insecticides,
- Metallic Salts, Nitrates, Oxides, Pesticides, Phosphates, Stearates, Talc, Urea Resin
Features
- Wholly made of stainless steel.
- Designed according to GMP standard.
- Crushing chamber can be equipped with water cooling jacket.
- Output size can be adjustable by changing different size of sieves.
- Can be equipped with a dust collecting device to remove the dust.
- Ultra fine powder grinding machine can be equipped with a cyclone separating device for a continuous production.
Advantages
- Simple structure, easy assembly and disassembly of crushing chamber, easy to clean, and can be replaced after tooth claw wear.
- Smooth operation, low noise, small vibration.
- Simple operation, replacing the screen can control the size of the particle size. Friendly tips for water cooling and explosion-proof devices
