Product Description
1)The Industrial Spray Drying Machine have fast drying speed, the material liquid by the centrifugal spray, to increase surface area, in the high temperature air, can evaporate 95-98% water by memont. it takes only a few seconds drying time.
2)Industrial Spray Drying Machine Suitable for heat-sensitive materials.Because the droplets and hot air flow and flow direction, although the hot air temperature is higher, but the material does not overheat during water evaporation.
3) Product has good dispersion, fluidity and solubility. because of the instantaneous drying, the product can maintain uniform fine granular.
| MODEL | LPG-5 |
| Inlet temperature (ºC) | 140~350 |
| Outlet temperature (ºC) | 80~90 |
| Water evaporation capacity(kg/h) | 5 |
| Revolution (rpm) | 25000 |
| Diameter of atomizing disc (mm) | 50 |
| Heat source | Electricity |
| Max. power of electric heater (kw) | 9 |
| Overall dimensions (m) | 1.8X0.93X2.2 |
| Recovery rate of dry powder (%) | ≥95 |
The working principle of industrial spray drying machine machine mainly includes the following steps: Air is turned into hot air through heater and enters into hot air distributor at the top of dry chamber and then enters into dry chamber and rotates in the state of helix. At the same time liquid of raw material is sent to centrifugal atomizer at the top of dry chamber through stepless variable screw pump. In which liquid of raw material atomizes small drops. Air and liquid of raw material flow and contact each other. The moisture vaporizes rapidly. Liquid of raw material is dried into finished product in a short time. The finished product is discharged through the bottom cyclone separator of drier and the wasted air is exhausted through fan.
Product Advantage
Product Specification
