Products Description
Conical Vacuum Dryer is a vertical, full-cone vessel equipped with a vertical screw mixing system for gentle mixing and drying of the product by means of an agitator at lower pressures. Due to its closed system and indirect heating of the product, the Conical Vacuum Dryer is particularly suitable for drying hazardous and toxic products to very low final moisture content.
The conical vacuum dryer works by utilizing its unique double helical stirrer (fully heated) to achieve a highly efficient heat transfer coefficient, while the combination of the toothed design and low-speed operation ensures gentle agitation of the product.
Structure design
Product Specification
|
Tank volume(L) |
100 |
350 |
500 |
750 |
1000 |
1500 |
2000 |
3500 |
4500 |
|
Charging volume(L) |
≤50 |
≤175 |
≤250 |
≤375 |
≤500 |
≤750 |
≤1000 |
≤1750 |
≤2250 |
|
Speed(rpm) |
0～6 |
||||||||
|
Motor power(kw) |
0.75 |
1.1 |
1.5 |
2 |
3 |
3 |
4 |
5.5 |
7.5 |
|
Floor space |
2160×800 |
2260×800 |
2350×800 |
2560×1000 |
2860×1300 |
3060×1300 |
3260×1400 |
3760×1800 |
3960×2000 |
|
Slewing height(h) |
1750 |
2100 |
2250 |
2490 |
2800 |
2940 |
2990 |
3490 |
4100 |
|
Tank design pressure(MPa) |
-0.1～0.15 |
||||||||
|
Jacket design pressure(MPa) |
≤0.3 |
||||||||
|
Working temperature(℃) |
in-tank≤85 jacket≤140 |
||||||||
|
Vacuum pump model and power when with condenser (kw) |
2X-15A |
2X-15A |
2X-30A |
2X-30A |
2X-70A |
JZJX300-8 |
JZJX300-4 |
JZJX600-8 |
JZJX600-4 |
|
Model and power of vacuum pump when without condenser(kw) |
SK-0.4 |
SK-0.4 |
SK-0.8 |
SK-2.7B |
SK-2.7B |
SK-3 |
SK-6 |
SK-6 |
SK-9 |
|
Weight(kg) |
800 |
1100 |
1200 |
1500 |
2800 |
3300 |
3600 |
6400 |
7500 |
Features
Conical Vacuum Dryer
- Fully conical vertical vessel
- Vertical Screw Mixing System
- Hygienic design, cGMP and FDA compliant
- Mechanical simplicity, low maintenance, easy to clean and inspect
Advantages
- Particularly suitable for drying hazardous and toxic products to very low final moisture content
- Unique and very gentle mixing characteristics, even for mechanically sensitive products without damaging their quality
Application
